4W Network Card Specifications
Basic Specifications
- Interface Type: USB 2.0
- Supported Protocol: 802.11ac
Physical Specifications
- Dimensions: 36mm × 36mm (Length × Height)
- Mounting Hole Distance: 30.5mm x 30.5mm
- Weight: 12.6g (16g with fan)
Electrical Specifications
-
Operating Voltage: 6V-28V
-
Power Consumption:
- Idle State: N/A
- Typical Operation: N/A
- Maximum Load: N/A
Product Image
Power Reference Table (20m Bandwidth)
| Frequency/Channel | MCS1 Bitrate 4MB | MCS1 Bitrate 4MB | Power(W) | MCS2 Bitrate 2MB | MCS2 Bitrate 4MB | MCS3 Bitrate 8MB | MCS3 Bitrate 10MB | MCS3 Bitrate 4MB | Driver_tx |
|---|---|---|---|---|---|---|---|---|---|
| 5180/36 | 36.1 | 32 | 13.2 | 35 | |||||
| 5200/40 | |||||||||
| 5220/44 | |||||||||
| 5240/48 | |||||||||
| 5260/52 | |||||||||
| 5280/56 | |||||||||
| 5300/60 | 36.4 | 32.4 | 14 | 25 | |||||
| 5320/64 | |||||||||
| 5500/100 | 36.9 | 32.8 | 14.5 | 8.5 | 10.8 | 14.8 | 17.5 | 9.5 | 40 |
| 5520/104 | |||||||||
| 5540/108 | |||||||||
| 5560/112 | |||||||||
| 5580/116 | |||||||||
| 5600/120 | 37 | 32.7 | 14.6 | 35 | |||||
| 5620/124 | |||||||||
| 5640/128 | |||||||||
| 5660/132 | |||||||||
| 5700/140 | 36.7 | 32.3 | 14.3 | 35 | |||||
| 5720/144 | |||||||||
| 5745/149 | |||||||||
| 5785/157 | |||||||||
| 5805/161 | 36.4 | 32 | 14.2 | 35 | |||||
| 5845/169 | |||||||||
| 5865/173 | |||||||||
| 5885/177 | 36.2 | 31.3 | 13.2 | 30 |
